Stainless Steel Flared Tube 3/4" OD, 1-1/16-12 Thread, 37 deg Flared Angle
$86.77
Payment Forms We Accept: Visa, Mastercard, Discover, American Express
Item #: 33662370
Brand: Made in USA
Model #: TX-12-GC
Product Specifications
| Flared Angle | 37 |
| Material | Stainless Steel |
| Thread Size | 1-1/16-12 |
| Thread Standard | UNF |
| End Connection | Flared to Male SAE O-Ring |
| Material Grade | 316 |
| Standards | SAE 070120; MS51525 |
| Max Working Pressure Dynamic | 6000 |
| Outside Diameter (Inch) | 3/4 |
| Overall Length (Decimal Inch) | 1.9700 |
| UNSPSC Code | 27121707 |
| Country of Origin | UNITED STATES |
