(Nibco Part#: H-81703W) 8170 Series - Full Port Forged Brass Ball Valves
$31.63
Payment Forms We Accept: Visa, Mastercard, Discover, American Express
Material #: H-81703W
Brand: Nibco
UPC Code #:
Product Specifications
| Industry Standards/Certifications | NSF/ANSI 61, NSF/ANSI 372 |
| Type | Ball Valve |
| Valve Size | 3/4 |
| Connection Type | Press |
| Valve Operator | Lever Handle |
| Weight | 0.77 lb |
| Maximum Temperature | 250 ºF |
| Maximum Operating Pressure | 250 psi |
| Stem Seal Material | PTFE |
| Seat Material | PTFE |
| Stem Material | Lead-Free Brass |
| Ball Material | Brass CP |
| Body Material | Brass |
| End Material | Brass |
| Packing Gland Material | PTFE |
| Packing Nut Material | Brass |
| Handle Material | Steel CP |
| Hex Nut Material | Stainless Steel |
| Inside Diameter (A) | 0.75 in |
| Length (B) | 4 7/16 in |
| Length (C) | .44 in |
| Length (D) | 0.75 in |
| Length (E) | 1.10 in |
| Handle Length (F) | 3.74 in |
