(Nibco Part#: H-80137W) 80X3W Series - Full Port Forged DZR Brass Ball Valve
$159.34
Best Price Guarantee - Email Us A Better Published Price and We'll Beat It
2% Off All Online Orders Use Code: 2%OFF
Fast Online Checkout - No Account Required
Material #: H-80137W
Brand: Nibco
UPC Code #:
Product Specifications
| Industry Standards/Certifications | NSF/ANSI 61, NSF/ANSI 372, NSF/ANSI 14 |
| Type | Ball Valve |
| Valve Size | 2 |
| Connection Type | Press x ASTM F1807 PEX |
| Valve Operator | Lever Handle |
| Weight | 4.37 lb |
| Maximum Temperature | 250 ºF |
| Maximum Operating Pressure | 250 psi |
| Stem Seal Material | PTFE |
| Seat Material | PTFE |
| Stem Material | Stainless Steel |
| Ball Material | Lead Free Brass |
| Body Material | Lead Free Brass |
| End Cup Material | Lead Free Brass |
| Packing Gland Material | Lead Free Brass |
| Handle Nut Material | Stainless Steel |
| Handle Material | Chrome Plated Steel |
| Length (A) | 6.88 in |
| Length (B) | 1.5 in |
| Length (C) | 1.55 in |
| Height (D) | 3.47 in |
| Handle Length (E) | 6.34 in |
