(Nibco Part#: H-80132W) 80X3W Series - Full Port Forged DZR Brass Ball Valve - Flow Control Products

(Nibco Part#: H-80132W) 80X3W Series - Full Port Forged DZR Brass Ball Valve

$22.72

Payment Forms We Accept: Visa, Mastercard, Discover, American Express


Material #: H-80132W
Brand: Nibco
UPC Code #:

Product Specifications

Industry Standards/Certifications NSF/ANSI 61, NSF/ANSI 372, NSF/ANSI 14
Type Ball Valve
Valve Size 1/2
Connection Type Press x ASTM F1807 PEX
Valve Operator Lever Handle
Weight 0.49 lb
Maximum Temperature 250 ºF
Maximum Operating Pressure 250 psi
Stem Seal Material PTFE
Seat Material PTFE
Stem Material Brass
Ball Material Lead Free Brass
Body Material Lead Free Brass
End Cup Material Lead Free Brass
Packing Gland Material Lead Free Brass
Handle Nut Material Stainless Steel
Handle Material Chrome Plated Steel
Length (A) 3.44 in
Length (B) 0.65 in
Length (C) 1.00 in
Height (D) 1.66 in
Handle Length (E) 3.74 in
