Solenoid Valve: 1/4" Port, NPT
$242.02
Payment Forms We Accept: Visa, Mastercard, Discover, American Express
Item #: 36912517
Brand: Parker
Model #: 73216BN2MT00
Product Specifications
| Valve Type | Direct-Acting |
| Valve Way & Position | 2-Way & 2-Position |
| Port Size | 1/4 in |
| Valve Unactuated State | Closed |
| Thread Standard | NPT |
| Body Material | Brass |
| Seal Material | Polytetrafluroethylene |
| Voltage | 120/60-110/50V AC |
| Maximum Working Pressure (PSI - 3 Decimals) | 1500 |
| Cv Factor Nc | 0.7600 |
| Overall Height (Decimal Inch) | 3.2500 |
| Overall Length (Decimal Inch) | 2.7600 |
| Orifice Size | 1/4 |
| Standards | UL Listed; NEMA 4X; CSA Certified |
| Coil Included | No |
| Special Item Information | Requires Integrated Coil for Complete Valve |
| Minimum Operating Pressure Differential | 5 |
| Maximum Temperature (F) ( - 0 Decimals) | 210 |
| Maximum Temperature (C) | 210 |
| UNSPSC Code | 40141605 |
