Steel Flared Tube Union: 3/16" OD, 37 deg Flared Angle
$29.47
Payment Forms We Accept: Visa, Mastercard, Discover, American Express
Item #: 79107041
Brand: Parker
Model #: 3 JTX-S
Product Specifications
| Fitting Type | Union |
| Flared Angle | 37 |
| Material | Steel |
| End Connection | Flare x Flare x Flare |
| Maximum Working Temperature (F) | 500 |
| Standards | ISO 8434-2; SAE 070401; SAE J514 |
| Max Working Pressure Dynamic | 7500 |
| Outside Diameter (Inch) | 3/16 |
| Maximum Working Temprature (Deg C) | 260 |
| Overall Length (Decimal Inch) | 1.6600 |
| UNSPSC Code | 27121707 |
| Country of Origin | UNITED STATES |
