Hydraulic Hose Male NPT Rigid Crimp Fitting: -20 Hose, 5000 psi
$76.97
Payment Forms We Accept: Visa, Mastercard, Discover, American Express
Item #: 46607305
Brand: Parker Hannifin
Model #: 10126-20-20
Product Specifications
| Fitting Type | Male NPT Rigid Crimp Fitting |
| Hose Inside Diameter (mm) | 28.58 |
| Hose Inside Diameter (Decimal Inch) | 1.1250 |
| Pressure Rating | 5000 |
| Hose Size | -20 |
| Material | Carbon Steel |
| Thread Type | Male NPTF |
| Thread Size (Inch) | 1-1/4-11-1/2 |
| Shape | Straight |
| Connection Type | Threaded |
| Maximum Working Pressure (PSI - 3 Decimals) | 5000.000 |
| Maximum Working Pressure (bar) | 344.74 |
| Overall Length (Decimal Inch) | 2.8300 |
| Overall Length (mm) | 72.0000 |
| Epa Watersense Certified | No |
| Series | 26 |
| Valve/Non-Valved | Non-Valved |
| Hose Outside Diameter (mm) | 38.00 |
| Hose Outside Diameter (Decimal Inch) | 1.5000 |
| UNSPSC Code | 40141734 |
| Country of Origin | UNITED STATES |
